Préparateur de commandes en hauteur (de 2,5 à 6m) Dragon Machinery CPCD20 Diesel neuf

2.0T diesel forklift, 2.0T diesel forklift truck, 2.0 ton diesel forklift, 2.0T diesel fork lift truck, 2T diesel forklift truck, 2T capacity diesel forklift, 2.0T capacity diesel forklift truck, 2.0T diesel powered forklift, 2.0T diesel fired forklift, 2.0 ton diesel powered fork lift trucks, 2.0 ton diesel fired fork lift truck, 2 ton diesel forklifts, 2 ton diesel forklift truck, diesel forklift truck 2.0T capacity, diesel forklift truck 2.0 ton capacity, 2000kg capacity diesel forklifts, 2.0 ton internal combustion forklifts, 2.0T internal combustion forklifts, 2 ton internal combustion fork lift truck, 2T internal combustion forklift truck, 2.0 ton counterbalance diesel forklift truck, 2.0T counterbalanced diesel forklifts

Features:
1. Intelligent Drive-monitoring System
The digital intelligent drive-monitoring system of our diesel forklift truck can facilitate obtaining the operation data of the diesel forklift easily, so as to achieve the whole-process control of the forklift.
2. Full Hydraulic Flexible Steering System
The full hydraulic steering system of our diesel forklifts can greatly reduce the fatigue of the operator. The steering system uses a horizontal oil cylinder on the compact steering axle and guarantees a reliable steering.
3. Classical Space Frame Structure
Our diesel forklift truck uses the classical YTO ASF space frame structure. It is ergonomically designed, aesthetic in appearance, compact in structure, and easy to operate.
4. Good-view Mast
The optimized rail section design of the mast enables the driver to enjoy a good and wide view.

Technical Specifications:
Model: CPCD20
Power Type: Diesel
Rated Capacity: 2000kg
Load Center: 500mm
Lifting Height: 3000mm
Mast Tilt Angel (F/R): 6/12 deg.
Front Overhang: 465mm
Wheel Base: 1600mm
Wheel Tread (F/R): 960/970mm
Dead Weight: 3540kg
Free Lift Height: 160mm
Min. Turning Radius: 21740mm
Min. Ground Clearance - Under Mast: 105mm
Min. Ground Clearance - Wheelbase Center: 150mm
Service Brake: Hydraulic Foot Pedal
Parking Brake: Mechanical Hand Lever
Lifting Speed (full-load): 550mm/s
Lowering Speed: Full-load < 600mm/s, No-load > 300mm/s
Travel Speed (no-load): 19km/h
Max. Gradeability (full-load): 20%
Max. Tractive Force (full-load/no-load): 16/12kN
Weight Distribution with load (F/R): 4650/890kg
Weight Distribution without Load (F/R): 1360/2180kg
Engine Model: C490BPG
Engine Manufacturer: XINCHANG
Engine Rated Power: 40kW/2650rpm
Max. Torque/rpm of Engine: 162N•m/1800rpm
Engine Displacement: 2.54L
Battery Voltage: 12V
Battery Capacity: 100Ah
Gearbox Transmission Type: Hydraulic torque converter
Gear Shift (F/R): I/I
Tyre Type: Pneumatic Tyres
Tyre Model - Front: 7.00-12-12PR
Tyre Model - Rear: 6.00-9-10PR
Fork Dimension: 40x125x1070mm
Overall Length (without fork): 2480mm
Overall Width: 1150mm
Overall Height - Mast Extended: 4030mm
Overall Height - Mast Lowered: 2000mm
Overall Height - Overhead Guard: 2120mm

Note:
1. Technical specifications are for standard models only.
2. Other optional accessories, functions and requirements are available upon request.
3. All specifications and design characteristics are subject to change without prior notice.

Optional Engine:
Model: XINCHAI A498BT1 (EURO III)
Rated Power: 36.8kW / 2650rpm
Max. Torque: 186 N•m /1680rpm
Displacement: 3.168L
OR
Model: ISUZU C240 (EURO III)
Rated Power: 34.6kW / 2500rpm
Max. Torque: 139 N•m /1800rpm
Displacement: 2.369L
